DATA SHEET
Housing material: Aluminium alloy
Valve en cap material: Zinc alloy or Makrolon
Spool and liner material: Steel, hardened, corrosion resistant
Duty cycle: Continuous 100%
Earthing contact: Part of the standard device
Electrical version: According to VDE 0580/VDE 0110 insulation group C
Electrical connections: Plug-in socket/flying lead, flat plug receptacles 2 x o.8 DIN 43650 or 6.3 x 0.8 DIN 46247
Mounting: Any position
Lubricant: Shell Tellus C10 or equivalent
Operating medium: 5 micron filtered, lubricated (or not) compressed air; also suitable for other media conforming to ISO-VG 10
