NOMINAL VOLTAGE AC/DC: 250V AC/DC
NOMINAL CURRENT: 10 A
CONTACT RESISTANCE: ≤5 MΩ
WIRE CROSS SECTION: MAX 1.5 MM2 (AWG 16)
CASING: PA6 GF
LED: NONE
NO. OF POLES: 2+GROUND (EARTH POSITION H12)
PROTECTION: IP 65 (IF CORRECTLY ASSEMBLED) GASKET: FLAT
COLOUR: BLACK
AMBIENT TEMPERATURE: FROM -40 °C TO +100 °C
